CXE Fixed Gas Detector

Compact design
Cost-effective
Sensor type: Catalytic sensor
Power: DC24V±6V
Electrical output: RS485 Power BUS

Overview

Description

CXE combustible gas detector is mainly used in small restaurants, shopping malls, underground integrated pipe corridors and other environments where gas may leak. When the gas concentration in the environment exceeds the preset alarming value, the indicator will give an alarm. At the same time, it can output signals and drive valves and other equipment to protect the user's personal and property safety.

Applications

Applicable to 9 small places such as industrial and commercial small restaurants, snack bars, barber shops, bathrooms, small hospitals, shopping malls etc.

Features

Compact design

Low power consumption

Stable transmission

Cost-effective

Technical Data

Sensor type	Catalytic sensor
Power	DC24V±6V
Electrical output	RS485 Power BUS
Operating temperature	-40～70℃
Closure material	Aluminum alloy
Relay capacity	3A@DC30V or 3A@AC250V
Ingress protection	IP66
Cable entry	NPT1/2
Dimensions	95mm x 106mm x 76.5mm
Ex grade	Ex d ⅡC T6 Gb / Ex tD A21 IP66 T80℃
State indication	Yellow-Fault, Red-Alarm, Green-Power
Extendable functions	Wireless: GPRS / NB-IoT Temperature and humidity collection function
